Conventional drill pipes are processed in strict accordance with the API 5DP standard, using internationally advanced thickening technology, heat treatment technology, friction welding technology and advanced production and testing equipment, not only providing users with conventional drills covering all API standard specifications and steel grades At the same time, through independent research and development to provide users with a variety of special and high-end products to meet the differentiated and personalized needs of customers.


Contact us

The outer and inner diameter welded gates are removed by shearing and machining. Perform post-weld heat treatment on the heat-affected zone between the drill pipe upsetting and the tool joint to restore the performance of the welded zone. Post-weld heat treatment is a quenching and tempering process. Through this process, the weld zone first reaches the austenitizing temperature, and then the polymer is quenched. Then, an area wider than the weld zone is reheated to the tempering temperature by induction. Each post-weld heat treatment will be monitored and recorded to form a comprehensive strip chart. Perform a 100% hardness inspection on each weld to confirm that they are fully tempered. The post-weld heat treatment process continues to produce stronger, tougher, more uniform welding performance and ideal microstructures to maximize resistance to stress and fatigue.

For each drill pipe component, from raw materials to all manufacturing completion, complete product and process traceability is maintained. For pin and box tool joints, the unified cutting test certificate is confirmed by the incoming material test. Each tool joint has a unique product number, which provides the traceability of the entire manufacturing process. The same procedure applies to pipeline traceability.

The surface near the weld is smooth on both the outer and inner diameters. Precision machining and grinding provide a surface finish without stress rise. We use wet magnetic powder and ultrasonic inspection technology to perform 100% inspection on each welding area. Destructive tests such as tensile, yield, impact and bending tests of welding coverings are carried out for each specification batch and recorded.


Product specifications

1) Product size: all specifications from 2-3/8" to 6-5/8"

2) Product steel grade: E75; X95; G105 and S135

3) Product length: R1 R2 R3

4) Thickened form: IU EU IEU

5) Thread type: from NC23 to NC50, 5-1/2”FH, 6-5/8”FH

6) Specification level: API 5DP; API 7-2, API RP7G; NS-1


Product quality control

1) 100% ultrasonic full length inspection of drill pipe body inspection rate;

2) 100% of the joints and weld areas adopt ultrasonic and magnetic particle inspection

3) Thickened transition zone MiuN 140mm: Miu-R>300mm reduces the stress concentration at the disappearance of the internal thickened transition zone and improves fatigue performance.


Performance of high cost-performance drill pipe

1) Joint up and down test, joint thread cold rolling

2) Wear belt: ARNCO 100 XT, 150 XT, 300 XT, 350 XT, Tuboscope TCS 8000x TCS Titanium, Duraband

3) Inner coating: DPC, TK34L, TK34P, TC2000

4) To meet stringent drilling conditions, high-performance drill pipes other than API PSL-1 & PSL-2 can be produced, including but not limited to API 5DP PSL-3, NS-K DS-1 or customized according to customer special requirements


Detection flow chart



2 3/8"-2 7/8"

No

Size OD

Nominal Weight(PPF)

Grade and upset type

Wall Thickness

Nominal ID


Pipe Body

Section Area

Connection

Type

Outside Diameter

Inside Diameter

Make-Up Torque

Torsional Ratio Tool

Joint to Pipe

Pin Tong Space

Box Tong Space

Adjusted Weight


In

mm

Ib/ft

Upset Type

in

mm

in

Sq/in

Type

in

in

ft-lb

Joint to Pipe

in

in

Ib/ft

kg/m

1

2 3/8

60.30

6.65

E-75 EU

EU

0.280

7. 11

1.815

1.843

NC26

3 3/8

1 3/4

3900

1.10

9

10

7.17

10.68

2

2 3/8

60.30

6.65

X-95 EU

EU

0.280

7.11

1.815

1.843

NC26

3 3/8

1 3/4

3900

0.87

9

10

7.17

10.68

3

2 3/8

60. 30

6.65

G-105 EU

EU

0.280

7. 11

1.815

1.843

NC26

3 3/8

1 3/4

3900

0. 78

9

10

7.17

10.68

4

2 3/8

60.30

6.65

S-135 EU

EU

0.280

7.11

1.815

1.843

NC26

3 5/8

1 1/2

4900

0.80

9

10

7.62

11.35

5

2 7/8

73.00

6.85

E-75 IU

IU

0.217

5.51

2.441

1.812

NC26

3 3/8

1 3 4

3900

0.85

9

10

7.19

10.71

6

2 7/8

73.00

6.85

E-75 EU

EU

0.217

5.51

2.441

1.812

NC31

41/8

2 5/32

6200

1.42

9

11

7. 88

11.74

7

2 7/8

73.00

6.85

X-95 IU

IU

0.217

5.51

2. 441

1.812

NC26

3 1/2

1 1/2

4900

0.86

9

10

7. 50

11.17

8

2 7/8

73.00

6.85

X-95EU

EU

0.217

5.51

2. 441

1.812

NC31

4 1/8

2 5/32

6200

1.13

9

11

7. 88

11.74

9

2 7/8

73.00

6.85

G-105IU

IU

0.217

5.51

2. 441

1.812

NC26

3 5/8

1 3/4

3900

0. 64

9

10

7. 46

11.11

10

2 7/8

73.00

6.85

G-105EU

EU

0.217

5.51

2. 441

1.812

NC31

4 1/8

2 5/32

6200

1.02

9

11

7. 88

11.74

11

2 7/8

73. 00

6.85

S-135IU

IU

0.217

5.51

.2. 441

1.812

NC26

3 5/8

1 1/2

4900

0. 62

9

10

7. 64

11.38

12

2 7/8

73. 00

6. 85

S-135EU

EU

0.217

5.51

2.441

1.812

NC31

4 1/8

2 1/8

6400

0.82

9

11

7.91

11.78

13

2 7/8

73. 00

10. 40

E-75EU

EU

0.362

9.19

2.151

2.858

NC31

4 1/8

2 1/8

6400

1.03

9

11

11.14

16. 59

14

2 7/8

73.00

10. 40

E-75EU

EU

0.362

9.19

2.151

2.858

NC26

3 1/2

1 1/2

4900

0.76

9

10

10. 79

16.07

15

2 7/8

73. 00

10. 40

X-95EU

EU

0.362

9.19

2.151

2.858

NC31

4 1/8

2

7100

0.90

9

11

11.27

16. 79

16

2 7/8

73. 00

10. 40

X-95IU

IU

0.362

9.19

2. 151

2.858

NC26

3 1/2

1 1/2

4900

0.60

9

10

10. 76

16.03

17

2 7/8

73. 00

10. 40

G-105EU

EU

0. 362

9.19

2.151

2. 858

NC31

4 1/8

2

7100

0.81

9

11

11.27

16. 79

18

2 7/8

73. 00

10. 40

G-105IU

IU

0. 362

9.19_

2.151

2.858

NC26

3 1/2

1 1/2

4900

0.54

9

10

10. 76

16.03

19

2 7/8

73. 00

10. 40

S-135EU

EU

0. 362

9.19

2.151

2.858

NC31

4 1/8

2

7100

0. 63

9

11

11.29

16. 82

20

2 7/8

73. 00

10.40

S-135IU

IU

0.362 1

9.19

2.151

2.858

NC26

3 5/8

1 1/2

4900

0.43

9

10

10. 90

16. 24



3 1/2"


No.

DRILL PIPE TABLES

Tool Joint Data

Assembly Data

Size OD

Nominal Weight(PPF)

Grade and upset type

Wall Thickness

Pipe Body

Nominal ID Section Area

Connection

Type

Outside Diameter

Inside Diameter

Make-Up Torque

Torsional Ratio Tool

Joint to Pipe

Pin Tong Space

Box Tong Space

Adjusted Weight




In

mm

Ib/ft

Upset Type

in

mm

in

Sq/in

Type

in

in

ft-lb

Joint to Pipe

in

in

Ib/ft

kg/m


21

3 1/2

88.90

9.50

E-75 EU

0.254

6.45

2.992

2.590

NC38

4 3/4

2 11/16

9700

1.28

10

12.5

11.07

16.49


22

3 1/2

88.90

9.50

E-75 IU

0.254

6.45

2.922

2.590

NC31

41/8

2 1/8

6400

0.84

9

11

10.49

15.62


23

3 1/2

88.90

9. 50

X-95 EU

0.254

6.45

2.922

2. 590

NC38

4 3/4

2 11/16

9700

1.01

10

12.5

11.07

16.49


24

3 1/2

88.90

9. 50

X-95 IU

0.254

6.45

2.922

2. 590

NC31

4 1/8

2

7100

0. 74

9

11

10.61

15.80


25

3 1/2

88.90

9. 50

G-105 EU

0.254

6.45

2.922

2. 590

NC38

4 3/4

2 11/16

9700

0.91

10

12.5

11.07

16.49


26

3 1/2

88.90

9. 50

G-105 IU

0.254

6.45

2.922

2. 590

NC31

41/8

2

7100

0.67

9

11

10.61

15.80


27

3 1/2

88.90

9. 50

S-135 EU

0.254

6.45

2.922

2. 590

NC38

4 7/8

2 9/16

10700

0. 79

10

12.5

11.45

17. 05


28

3 1/2

88.90

9. 50

S-135 IU

0.254

6.45

2.922

2. 590

NC31

4 1/8

2

7100

0. 52

9

11

10.61

15.80


29

3 1/2

88.90

13. 30

E-75 EU

0. 368

9. 35

2. 764

3.621

NC38

4 3/4

2 11/16

9700

0.97

10

12.5

14. 24

21.21


30

3 1/2

88.90

13. 30

E-75 IU

0. 368

9. 35

2.764

3.621

NC31

4 1/8

2

7100

0.71

9

11

13.93

20.75


31

3 1/2

88.90

13. 30

X-95 EU

0. 368

9. 35

2. 764

3.621

NC38

5

2 9/16

10700

0.86

10

12.5

14.84

22.10


32

3 1/2

88.90

13. 30

X-95 IU

0. 368

9.35

2. 764

3.621

NC31

4 1/8

2

7100

0. 56

9

11

13.93

20.75


33

3 1/2

88.90

13. 30

G-105 EU

0. 368

9. 35

2. 764

3.621

NC38

5

2 7/16

11700

0.85

10

12.5

15. 00

22. 34


34

3 1/2

88.90

13. 30

G-105 IU

0. 368

9.35

2. 764

3.621

NC31

4 1/8

2

7100

0.51

9

11

13.93

20.75


35

3 1/2

88.90

13. 30

S-135 EU

0. 368

9. 35

2. 764

3.621

NC38

5

2 1/8

14000

0. 79

10

12.5

15. 37

22.89


36

3 1/2

88.90

13. 30

S-135 IU

0. 368

9.35

2. 764

3.621

NC31

4 1/8

2

7100

0.40

9

n

13.93

20.75


37

3 1/2

88.90

15. 50

E-75 EU

0.449

11.40

2.602

4. 304

NC38

5

2 9/16

10700

0.96

10

12.5

16.94

25. 23


38

3 1/2

88.90

15. 50

X-95 EU

0.449

11.40

2.602

4. 304

NC38

5

2 7/16

11700

0.83

10

12.5

17.11

25.49


39

3 1/2

88.90

15. 50

G-105 EU

0.449

11.40

2.602

4. 304

NC38

5

2 1/8

14000

0.90

10

12.5

17. 50

26. 07


40

3 1/2

88.90

15. 50

G-105 EU

0.449

11.40

2.602

4. 304

NC40

5 1/4

2 9/16

14600

0.94

9

12

17.24

25.68


41

3 1/2

88.90

15. 50

S-135 EU

0.449

11.40

2.602

4. 304

NC38

5

2 1/8

14000

0. 70

10

12.5

17. 50

26. 07


42

3 1/2

88.90

15. 50

S-135 EU

0.449

11.40

2.602

4. 304

NC40

5 1/2

2 1/4

17100

0.87

10

12.5

18.31

27.27


4 1/2"


No.

DRILL PIPE TABLES

Tool Joint Data


Size OD

Nominal Weight(PPF)

Grade and upset type

Wall Thickness

Pipe Body

Nominal ID Section Area

Connection

Type

Outside Diameter

Inside Diameter

Make-Up Torque

Torsional Ratio Tool

Joint to Pipe

Pin Tong Space

Box Tong Space

Adjusted Weight



In

mm

Ib/ft

Upset Type

in

mm

in

Sq/in

Type

in

in

ft-lb

Joint to Pipe

in

in

Ib/ft

kg/m

43

4

101. 60

11.85

E-75

IU

0.262

6. 65

3.476

3.077

NC40

5 1/4

2 13/16

12400

1.21

9

12

13.41

19.97

44

4

101. 60

11.85

X-95

IU

0.262

6. 65

3.476

3.077

NC40

5 1/4

2 13/16

12400

0.95

9

12

13.41

19.97

45

4

101. 60

11.85

G-105

IU

0. 262

6. 65

3. 476

3.077

NC40

5 1/4

2 13/16

12400

0.86

9

12

13.41

19.97

46

4

101. 60

11.85

S-135

IU

0.262

6. 65

3. 476

3.077

NC40

5 1/2

2 9/16

14600

0.80

9

12

14. 23

21.20

47

4

101. 60

11.85

E-75

IU

0. 330

8. 38

3. 340

3.805

NC40

5 1/4

2 13/16

12400

1.01

9

12

15. 64

23. 30

48

4

101. 60 101.60

11.85

E-75

EU

0. 330

8. 38

3.340

3.805

NC46

6

3 1/4

17600

1.44

9

12

16.51

24. 59

49

4

101. 60

11.85

X-95

IU

0. 330

8. 38

3. 340

3.805

NC40

5 1/4

2 11/16

13500

0.87

9

12

15.82

23. 56

50

4

101. 60

11.85

X-95

EU

0. 330

8. 38

3. 340

3.805

NC46

6

3 1/4

17600

1.14

9

12

16.51

24. 59

51

4

101. 60

11.85

G-105

IU

0. 330

8. 38

3. 340

3.805

NC40

5 1/2

2 7/16

15600

0.92

9

12

16. 62

24. 76

52

4

101. 60

11.85

G-105

EU

0. 330

8. 38

3.340

3.805

NC46

6

3 1/4

17600

1.03

9

12

16.51

24. 59

53

4

101. 60

11.85

S-135

IU

0. 330

8. 38

3. 340

3.805

NC40

5 1/2

2

18900

0.87

9

12

17.15

25. 54

54

4

101. 60

11.85

S-135

EU

0. 330

8. 38

3. 340

3.805

NC46

6

3

20500

0.94

9

12

16.90

25.17

55

4

101. 60

15. 70

E-75

IU

0. 380

9. 65

3. 240

4.322

NC40

5 1/4

2 13/16

12400

0.91

9

12

17. 22

25. 65

56

4

101. 60

15. 70

E-75

EU

0. 380

9. 65

3.240

4.322

NC46

6

3

20500

1.52

9

12

18. 34

27. 32

57

4

101. 60

15. 70

X-95

IU

0. 380

9. 65

3. 240

4. 322

NC40

5 1/4

2 9/16

14600

0.85

9

12

17. 57

26.17

58

4

101. 60

15. 70

X-95

EU

0. 380

9. 65

3. 240

4.322

NC46

6

3

20500

1.20

9

12

18. 49

27.54

59

4

101. 60

15. 70

G-105

IU

0. 380

9. 65

3. 240

4.322

NC40

5 1/2

2 7/16

15600

0.83

9

12

18. 20

27.11

60

4

101.60

15. 70

G-105

EU

0.380

9.65

3. 240

4.322

NC46

6

3

20500

1.09

9

12

18.49

27. 54

61

4

101. 60

15. 70

S-135

IU

0. 380

9. 65

3. 240

4. 322

NC40

5 1/2

2

18900

0. 78

9

12

18. 73

27.90

62

4

101. 60

15. 70

S-135

EU

0. 380

9. 65

3. 240

4.322

NC46

6

3

20500

0.84

9

12

18.49

27. 54

63

4 1/2

114. 30

16. 60

E-75

IEU

0. 337

8. 56

3.826

4. 407

NC46

6 1/4

3 1/4

17600

1.10

9

12

19.14

28.51

64

4 1/2

114. 30

16. 60

E-75

IEU

0. 337

8. 56

3.826

4. 407

4 1/2 FH

6

3

17600

1.13

9

12

19.03

28. 35

65

4 1/2

114. 30

16. 60

E-75

EU

0. 337

8. 56

3.826

4. 407

NC50

6 5/8

3 3/4

19800

1.24

9

12

19.19

28. 58

66

4 1/2

114. 30

16. 60

X-95

IEU

0. 337

8. 56

3.826

4. 407

NC46

6 1/4

3 1/4

17600

0.87

9

12

19.14

28.51

67

4 1/2

114. 30

16. 60

X-95

IEU

0. 337

8. 56

3. 826

4. 407

4 1/2 FH

6

3

17600

0.89

9

12

19. 03

28. 35

68

4 1/2

114. 30

16. 60

X-95

EU

0. 337

8. 56

3.826

4. 407

NC50

6 5/8

3 3/4

19800

0.98

9

12

19.19

28. 58

69

4 1/2

114. 30

16. 60

G-105

IEU

0. 337

8. 56

3.826

4. 407

NC46

6 1/4

3

20500

0.92

9

12

19. 57

29.15

70

4 1/2

114. 30

16. 60

G-105

IEU

0. 337

8. 56

3.826

4. 407

4 1/2 FH

6 1/4

2 3/4

20100

0.93

9

12

19.96

29. 73

71

4 1/2

114. 30

16. 60

G-105

EU

0. 337

8. 56

3. 826

4. 407

NC50

6 5/8

3 3/4

19800

0.88

9

12

19.19

28. 58

72

4 1/2

114. 30

16. 60

S-135

IEU

0. 337

8. 56

3.826

4. 407

NC46

6 1/4

2 3/4

23200

0.81

9

12

19.96

29. 73

73

4 1/2

114. 30

16. 60

S-135

IEU

0. 337

8. 56

3.826

4. 407

4 1/2 FH

6 1/4

2 3/4

20100

0. 72

9

12

19.96

29. 73

74

4 1/2

114. 30

16. 60

S-135

EU

0. 337

8. 56

3.826

4. 407

NC50

6 5/8

3 1/2

23400

0.81

9

12

19. 65

29. 27

75

4 1/2

114. 30

20. 00

E-75

IEU

0. 430

10.92

3.640

5. 498

NC46

6 1/4

3

20500

1.08

9

12

22.89

34.09

76

4 1/2

114. 30

20. 00

E-75

EU

0. 430

10.92

3.640











Products
